| Service: | Noncoating compatible liquids |
|---|---|
| Temperature Limits: | Process: 200°F (93.3°C); Ambient: 175°F (79.4°C) |
| Pressure Limit: | Limit: 200 psig (13.8 bar) |
| Repeatability: | ±0.02"; (0.5 mm) |
| Switch Type: | NPN open collector |
| Power Requirements: | 10 to 28 VDC |
| Output Signal: | Vout (max) = 28 VDC, Isink (max) = 100 mA |
| Current Consumption: | 35 mA maximum |
| Electrical Connections: | 22 AWG, 18" (460 mm) long |
| Process Connection: | 1/2" male NPT |
