Cleveland Controls RFS-4300-111 Low Air Flow Switch 0.15"

Name: Cleveland Controls RFS-4300-111 Low Air Flow Switch 0.15"
Brand: Cleveland Controls
SKU: RFS-4300-111
Price: 51.61 USD
Availability: InStock

Images for general purposes only. Actual may be different than depicted.

Cleveland Controls RFS-4300-111 Low Air Flow Switch 0.15"

SKU: RFS-4300-111

Tariff HS Code: 90330000

Brand:

Rating:

Quantity	Price	Stock
27 Usually Ships 1-2 Weeks	$51.61 /ea	27

Add to Cart

Add to Wishlist

Add to Cart

Add to Wishlist

Cleveland Controls RFS-4300-111 Low Air Flow Switch 0.15"

Series RFS-4000 is a line of general purpose proving switches designed for HVAC and Energy Management applications. These switches can be used to sense positive, negative, or differential air pressure. The plated housing encloses a diaphragm, a snap-acting switch, and an optional calibration spring (in adjustable set point models). The sample line connections located on each side of the diaphragm accept rigid or flexible tubing. Various electrical connections are available. An optional enclosure cover can be provided to protect the operator from accidental contact with the live switch contacts. The enclosure cover has five knockouts for a ½" conduit connection.

Electrical Rating	300 VA pilot duty at 115 to 277 VAC; 15 amp noninductive to 277 VAC, 60 Hz.
Measured Media	Air or combustion by-products that will not degrade silicone.
Operating Temperature Range	-40 to 180 ÂºF (â€“40.0 to 82.2 ÂºC)
Electrical Connection	1/4", 90Â° quick-connect spade terminals
Maximum Pressure	1/2 psi (0.03 bar)

Download Product Information:

Cleveland Controls RFS-4000 Series Air Flow Sensing Switches Technical Datasheet
